DHWS10-02SC auto flush solenoid valve

Product name：DHWS10-02SC auto flush solenoid valve
Item：
Details：
DHWS10 Series Small diaphragm plastic solenoid valve,2WAY NC Characteristic: 1.Direct acting miniature construction at low power consumption 2.Food class body material available for RO system, Washer, miller, etc Medium: Air, Water, etc Temperature: NBR Seal: 14F to 176F, -10 to 80 Silicon Rubber Seal: -10℃ to 80℃ Pressure: DHWS10: 0 ~ 7 bar DHWA10-04: 0~0.5 bar Port Size: See data below Port Thread: BSPP, BSPT, NPT Orifice (mm): 10mm Voltage: DC - 12V, 24V AC - 24V, 120V, 240V/60HZ 110V, 220V/50HZ Tolerance: +/- 10% Coils : SA41B，6VA(AC),6W(DC),IP65,100%ED Material: Body – Nylon (food class) Seal -VITON, NBR, EPDM Armature Tube - Stainless Steel 304 Plunger - Stainless Steel 430F Stop -SS430F Springs - SS 304 DHWS10-02SC (18 seconds Auto flush and adjustable) Media: Water, air, oil, etc. Media TEP: -10℃ to 80℃ Body: PP Pre: 0-8.0 Bar Port: NPT 1/4″ Orifice: DN10 Seal: NBR, Silicon rubber
