DHWS10-01-22 Normally open plastic solenoid valve

DHWS10-01-22 Normally open plastic solenoid valve


Product name:DHWS10-01-22 Normally open plastic solenoid valve
Item:
Details:
DHWS10 Series Small diaphragm plastic solenoid valve, 2WAY NO
Characteristic: 1.Direct acting miniature construction at low power consumption
                       2.Food class body material available for RO system, Washer, miller, etc
Medium:         Air, Water, etc
Temperature:  NBR Seal: 14F to 176F, -10 to 80
                      Silicon Rubber Seal: -10℃ to 80℃
Pressure:        DHWS10: 0 ~ 7 bar
                      DHWS10-02-22:    0 ~ 8 bar
Port Size:        See data below
Port Thread:    BSPP, BSPT, NPT
Orifice (mm):    10mm
Voltage:           DC - 12V, 24V
                       AC - 24V, 120V, 240V/60HZ 110V, 220V/50HZ
Tolerance:        +/- 10%
Coils :             SA41B,6VA(AC),6W(DC),IP65,100%ED
Material:         Body – Nylon (food class)
                      Seal -VITON, NBR, EPDM
                      Armature Tube - Stainless Steel 304
                      Plunger - Stainless Steel 430F
                      Stop -SS430F
                      Springs - SS 304
DHWS10-02-22 Normally OPEN
Media:         Water, air, oil, etc.
Media TEP: -10℃ to 80℃
Body:           PP
Pre:              0-8.0 Bar
Port:             NPT 1/4″
Orifice:         DN10
Seal:            NBR, Silicon rubber
